2023 Model Year

Ford F150

Towing capacity by configuration — 13 variants

14,000lbs max tow
2023 Ford F150

Model Year

20262025202420232022202120202019

Browse by Trim

RaptorRaptor RXL/XLTXL/XLT/LariatXL/XLT/Lariat/King Ranch/Platinum/LimitedXLT/LariatXLT/Lariat/King Ranch/PlatinumXLT/Lariat/King Ranch/Platinum/Limited

Towing Calculator

Driver Weight (lbs)
Passengers
Avg Passenger Weight (lbs)
Bed Cargo Weight (lbs)
Trailer Tongue Weight (lbs)
ℹ

Per SAE J2807, the max tow rating already assumes a 300 lbs baseline (driver + 1 passenger at 150 lbs each). Only weight above that baseline reduces your available tow.

Penalty: 0 lbs above baseline⚡ Tow package required: Max Trailer Tow Package (53C)
Payload Capacity180 / 1,700 lbs
Available Towing Capacity
14,000lbs

Max tongue weight: 1,400 lbs

This calculator uses the SAE J2807 standard. Always consult your vehicle owner's manual and verify ratings with your dealer before towing.

Engine
Cab
Bed
Drive
Max Tow
Payload
3.5L V6 gasoline
400 hp · 500 lb-ft
Crew Cab
Standard Bed
2WD
14,000lbs
pkg req.
1,700lbs
3.5L V6 gasoline
400 hp · 500 lb-ft
Double Cab
Long Bed
2WD
14,000lbs
pkg req.
1,910lbs
3.5L V6 gasoline
400 hp · 500 lb-ft
Crew Cab
Short Bed
4WD
13,800lbs
pkg req.
1,640lbs
5L V8 gasoline
400 hp · 410 lb-ft
Crew Cab
Short Bed
2WD
13,000lbs
pkg req.
1,950lbs
5L V8 gasoline
400 hp · 410 lb-ft
Regular Cab
Long Bed
2WD
13,000lbs
pkg req.
2,440lbs
3.5L V6 hybrid
430 hp · 570 lb-ft
Crew Cab
Short Bed
2WD
12,700lbs
pkg req.
1,840lbs
3.5L V6 hybrid
430 hp · 570 lb-ft
Crew Cab
Short Bed
4WD
12,300lbs
pkg req.
1,710lbs
2.7L V6 gasoline
325 hp · 400 lb-ft
Crew Cab
Short Bed
4WD
10,100lbs
pkg req.
1,510lbs
5.2L V8 gasoline
700 hp · 640 lb-ft
Crew Cab
Short Bed
4WD
8,700lbs
1,440lbs
2.7L V6 gasoline
325 hp · 400 lb-ft
Regular Cab
Long Bed
2WD
8,600lbs
pkg req.
2,120lbs
3.5L V6 gasoline
450 hp · 510 lb-ft
Crew Cab
Short Bed
4WD
8,200lbs
1,385lbs
3.3L V6 gasoline
290 hp · 265 lb-ft
Regular Cab
Long Bed
2WD
8,200lbs
pkg req.
1,985lbs
3.3L V6 gasoline
290 hp · 265 lb-ft
Crew Cab
Short Bed
2WD
8,100lbs
pkg req.
1,595lbs

* Amber values indicate highest available tow rating. "pkg req." = tow package required.

Frequently Asked Questions

The 2023 Ford F150 can tow between 8,100 and 14,000 lbs, depending on the engine, cab style, bed length, and drivetrain. The maximum rated towing capacity of 14,000 lbs is achieved with the optimal configuration when properly equipped.

The 3.5L V6 gasoline delivers the highest towing capacity on the 2023 Ford F150, rated at up to 14,000 lbs. It produces 400 hp and 500 lb-ft of torque.

Yes — reaching the maximum towing capacity of 14,000 lbs on the 2023 Ford F150 requires the Max Trailer Tow Package (53C) tow package. Without it, towing ratings on some configurations are significantly lower. The package typically adds a trailer hitch receiver, upgraded transmission cooler, integrated trailer brake controller, and a higher-output alternator.

On the 2023 Ford F150, the 2WD configuration tows more — up to 14,000 lbs versus 13,800 lbs for 4WD, a difference of 200 lbs. The 2WD variant's advantage comes from a lower curb weight, which directly increases available towing capacity.

The Crew Cab cab tows the most on the 2023 Ford F150, rated up to 14,000 lbs. Other cab styles are: Double Cab (14,000 lbs), Regular Cab (13,000 lbs).

The tongue weight limit for the 2023 Ford F150 ranges from 810–1,400 lbs depending on configuration. Tongue weight — the downward force your trailer hitch applies to the truck — should be kept between 10% and 15% of your total trailer weight. Exceeding the tongue weight limit can cause trailer sway and loss of steering control even when within the max tow rating.
